Equitilt® Architectural Walling
View DetailModule Width 1200 COLORBOND® Yes BCA Compliant Yes Availability Nationally CodeMark™ Accredited Yes Thickness/R-Values Thickness 50 75 100 125 150 200 250 Declared R-value (m2K/W) at 23℃ 1.20 1.80 2.40 3.00 3.60 4.85 6.05 Total R-value (m2K/W) at 15℃ (Winter) 1.41 2.04 2.66 3.28 3.91 5.16 6.41 Total R-value (m2K/W) at 30℃ (Summer) 1.36 1.94 2.53 3.13 3.72 4.91 6.09 -
LuxeWall®& LuxeWall FlameGuard®Luxury Living
View DetailModule Width 900 COLORBOND® Yes BCA Compliant Yes CodeMark™ Accredited Yes Availability Nationally, Locally manufactured Thickness/R-Values Product LuxeWall® LuxeWall FlameGuard® Thickness (mm) 50 75 Total R-value (m2K/W) at 15°C (Timber Framing) 1.8 2.4 Total R-value (m2K/W) at 30°C (Timber Framing) 1.9 2.5 -
MetecnoInspire®PIR Secret-Fix Wall Panel
View DetailModule Width 1100 FM Approved Yes COLORBOND® Yes BCA Compliant Yes Availability Nationally CodeMark™ Accredited Yes Thickness/R-Values Thickness 50 60 80 100 Declared R-value (m2K/W) at 23℃ 2.20 2.65 3.55 4.45 Total R-value (m2K/W) at 15℃ (Winter) 2.49 2.96 3.89 4.83 Total R-value (m2K/W) at 30℃ (Summer) 2.31 2.74 3.60 4.46 CodeMark Certificate of Conformity BAL/Bushfire Compliance Technical Data Sheet Product Specification Information Guide
A range of inspiring Architectural Facade Wall Cladding systems
Bondor® now offers Australian architects, designers and builders the widest possible choice in high quality, decorative insulated wall facades. With a range of new technologies including PIR, EPS-FR and Mineral Wool and finishes to suit a wide range of applications, performance requirements and budgets, Bondor®’s range of architectural decorative insulated facades can help you design a landmark building envelopment. Contact Bondor’s architectural specification team for more information on any of the below products.
Equitilt® is an insulated architectural facade panel offering supreme energy efficiency in a wide variety of vivid colours and finishes, made exclusively from BlueScope® steel. Equitilt® offer designers a functional and versatile product that is aesthetically stunning, quick to install and reduces energy consumption for the life of a building.
Inspire® is Bondor’s latest concealed fixed architectural facade system. Five different external surface profiles, multiple standard BlueScope® colours as well as corporate colour match options provide aesthetic variety, unmatched thermal performance and quicker build times.
