SolarSpan® Insulated Roof Panel

EPS-FR

SolarSpan® is Australia’s leading insulated roofing panel offering long-spans, low pitch and high thermal efficiency to satisfy Section J requirements in commercial, industrial and residential applications. Developed over 20 years ago this engineered all-in-one insulated roofing solution offers a ceiling, insulation and roof sheet in one product for optimal thermal and build efficiency when constructing high performance building envelopes. CodeMark™ approved and Australian Standards tested SolarSpan® features a COLORBOND® steel exteriorroof layer, an EPS-FR rigid insulation core with a pre-finished COLORBOND® ceiling underside,

SolarSpan® insulated roofing is faster to install than conventional roofing, eliminates the need for additional structural supports and extra layers as required in traditional roofing system eliminating purlins, beams, trusses, mesh, sarking, insulation and plasterboard as well as reducing the need for mutliple trades onsite.

Advantages

  • Meets Section J Thermal Requirements
  • Faster to install than traditional roofing methods
  • Long Spans
  • Low Pitch and compatible with superior end lap SecureLap® system
  • Made in Australia for Australian Conditions, tried and tested in Cyclonic regions
  • Compatible with SecureLap® superior End Lap system to eliminate reliance on sealants and butyl tape

Project Applications

  • Retail & Shopping Centre Roofs
  • Commercial
  • Educational Facilities – gymnasiums, assembly areas, auditoriums and classrooms
  • Warehouses
  • Residential House Roofs
  • Shaded structures and awnings
Fast Facts
Module Width 1000
COLORBOND® Yes
BCA Compliant Yes
Availability Nationally, Manufactured Locally
CodeMark™ Accredited Yes
THICKNESS / R-VALUES
Thickness 5075100125150175200
Declared R-value (m2K/W) at 23℃ 1.201.802.403.003.604.254.85
Total R-value (m2K/W) at 15℃ (Winter) 1.402.032.653.273.904.525.15
Total R-value (m2K/W) at 30℃ (Summer) 1.381.982.573.133.674.354.95
PRODUCT CORE OPTIONS

Expanded Polystyrene with fire-retardant (EPS-FR)

Plain Profile

Plain Profile

VJ Profile

Colour Palette
  • Basalt®

  • Classic Cream®

  • Dune®

  • Jasper®

  • Manor Red®

  • Pale Eucalypt®

  • Paperbark®

  • Shale Grey®

  • Surfmist®

  • Windspray®

  • Woodland Grey®
